1008L Large Volume Ultra-low Laboratory Freezer

LDW-FL1008
LABOAO offers the 1008L -40℃ medical freezer from china manufacture. It's with high-quality refrigeration system for fast cooling. The high-precision temperature control system can display various parameters simultaneously, including power voltage, temperature inside the cabinet and environmental temperature, which can indicate the operation status clearly. And you are free to set the temperature inside the cabinet in the range of -20°C to 40°C. The two-layer heat insulation foamed door with airbag-typed outer steal can prevent loss of refrigerating capacity in an effective way.
  • Volume1008L
  • Temperature Range-40°C~-86°C
  • Power1850W
  • Net Weight430kg
  • Interior Dimensions1362×1025×2002mm
  • Exterior Dimensions1022×696×1378mm
Request QuotationChat Now
  • Whatsapp

    WhatsApp Chat

  • WeChat

    WeChat Chat

OVERVIEW

-40°C large volume low temperature freezer LDW-FL1008 lab freezer is equipped with high-quality refrigeration system for fast cooling. The high-precision temperature control system can display various parameters simultaneously, including power voltage, temperature inside the cabinet and environmental temperature, which can indicate the operation status clearly. And you are free to set the temperature inside the cabinet in the range of -20°C to 40°C. The two-layer heat insulation foamed door with airbag-typed outer steal can prevent loss of refrigerating capacity in an effective way.


High Efficiency Refrigeration System
Freon-free refrigerant, compressor supplied by an international famous brand and  EBM fan can guarantee fast cooling and are energy-saving and environmentally friendly;
Refrigerating circuit with proprietary intellectual property rights ensures high efficiency and stability;
Two-layer heat insulating foamed door and the insulation design of the outer door system with multiple patents can prevent loss of refrigerating capacity in an effective way;
The cabinet are made from high-performance insulation material,  improving thermal insulation performance to a large extent.


High-precision Temperature Control System
High-precision microcomputer temperature control system and platinum resistor temperature sensors ensure more precise temperature control.


Human-oriented Design
High-quality steel plate structure with phosphate coating, Galvanized steel sheet (optional stainless steel)  liner and low noise design can create a comfortable environment.

FEATURES

1. The digital temperature display can show various parameters simultaneously, such as temperature inside the cabinet, power voltage and environmental temperature, indicating operating status clearly.

2. The high-precision microcomputer temperature control system and platinum resistor temperature sensors enable users to set temperature inside the cabinet within a range from -20℃ to -40℃.

3. The compressor supplied by an international famous brand and EBM fan is powerful, energy-saving and highly efficient The large-area finned condenser is characterized by a space equal to or less than 2mm between fins, providing a large area for heat dissipation and satisfactory performance.

4. The two-layer heat insulating foamed door with airbag-typed outer seal and the insulation design of the outer door system with multiple patents can prevent loss of refrigerating capacity in an effective way.

5. The cabinet are made from high-performance vacuum insulation material, improving thermal insulation performance to a large extent.

6. The well-developed alarm system has multiple alarm functions: high temperature/low temperature alarm, door ajar alarm, power failure alarm, abnormal voltage alarm, sensor failure alarm, low battery alarm, alarm of poor heat dissipation of condenser, system failure alarm, etc. The turn-on delay and stopping interval protection function can ensure reliability in running The keyboard lock function and password protection function can prevent any adjustment of operating parameters without permission.

7.The rotating handle facilitates door opening The adjustable layered structure is convenient for storage of various things.

8. The liner made from Galvanized steel sheet (optional stainless steel 304)  for medical use is low- temperature tolerant and corrosion-resistant, which has a long service life and is easy to clean.

SPECIFICATIONS

Model

LDW-FL1008

Specifications

Shelf/drawer QTY

Stainless   steel shelf/3

Cooling

 Direct cooling

Defrost

Manual

Refrigerant

R290

Ambient temperature(℃)

16~32

Temperature range(℃)

-20~-40℃

Cooling system

Compressor QTY

2

Temperature controller

Microprocessor

Display

Digital   display

Power

Voltage/frequencyV/Hz)

220-240~/50

PowerW)

1850W

CurrentA)

8.5

Material

Inside material

Galvanized   steel sheet

Outside material

High   quality steel plates with spraying

Insulation Thickness(mm)

130

Size

CapacityL)

1008

NT./GT.kg)

320/394

Exterior size(W*D*H)(mm)

1360*1006*1980

Interior size(W*D*H)(mm)

1022*696*1378

Package size(W*D*H)(mm)

1473*1155*2176

Alarm

High/low temperature

Y

Power failure

Y

Sensor error

Y

Main board communication error

Y

Built-in data logger USB failure

Y

Condenser overheating failure

Y

System failure

Y

Door ajar

Y

Accessory

Castor

4+2 leveling feet

Inside door

2

Test hole   QTY/diameter

3pcs. Ø 25 mm

USB port

Y

Backup Battery

Y


Remote alarm contact

Y

Optional

Chart recorder

Optional

CO2 backup system

Optional

Certification

Certification

ISO,CE

5 Good Reasons To Choose LABOAO 1008L Large Volume Ultra-low Laboratory Freezer
