Stainless Steel Self Pressurized Liquid Nitrogen Tank

YDZ Series
Liquid nitrogen tank is made of aviation aluminum and structured with high-vacuumed super adiabatic multi-layers. It is light by weight and the daily evaporation rate of liquid nitrogen is very low.
Request QuotationChat Now
  • Whatsapp

    WhatsApp Chat

  • WeChat

    WeChat Chat

OVERVIEW

The self-pressurized liquid nitrogen tank uses a small amount of liquid nitrogen in the tank to vaporize to generate pressure, so that the tank can automatically discharge the liquid nitrogen, so as to supplement the liquid nitrogen for other containers. It is mainly used to transport and store liquid media, and can also be used as a cold source for other refrigeration devices. It can be equipped with liquid nitrogen tank monitoring terminal and monitoring software, which can realize the remote transmission of liquid nitrogen level, pressure and other data, realize low liquid level, overpressure remote alarm, and can also manually remotely pressurize and control replenishment. At present, it is widely used in mold industry, animal husbandry, medicine, semiconductor, food, low temperature chemical industry, aerospace, military and other industries and fields.

FEATURES

1. All stainless steel manufacturing, high strength of the tank;

2. Unique tank support, good tank stability;

3. High-strength casters, more convenient to move;

4. Optional KF sealing neck;

5. Double safety valve structure to ensure product safety;

6. Adopting high vacuum and multi-layer insulation technology;

7. Ensure a high-quality vacuum layer: all welds are leak-checked by helium mass spectrometer;

8. Unique polishing technology, beautiful appearance;

9. High-quality activated carbon: oil-free, fat-free thin composite insulation material.

SPECIFICATIONS

Model

YDZ-30

YDZ-50

YDZ-100

YDZ-200

YDZ-230

YDZ-300

YDZ-500

Capacity(L)

30

50

100

200

230

300

500

Outer   diameter(mm)

404

455

556

656

656

806

958

Height(mm)

850

960

1100

1300

1400

1410

1500

Empty   weight(kg)

42

50

68

125

140

205

265

Caliber(mm)

50

50

50

50

50

50

50

Daily   evaporation rate of static liquid nitrogen(%)

3

2

1.2

1

1

0.8

0.8

Standard   working pressure(Mpa)

0.05

0.05

0.05

0.05

0.05

0.05

0.05

Max.   working pressure(Mpa)

0.09

0.09

0.09

0.09

0.09

0.09

0.09

Infusion   volume(L/min)

≥5

≥5

≥5

≥10

≥10

≥15

≥15

First   opening pressure of safety valve(Mpa)

0.099

0.099

0.099

0.099

0.099

0.099

0.099

Second   opening pressure of safety valve(Mpa)

0.15

0.15

0.15

0.15

0.15

0.15

0.15

Bursting   pressure of rupture disc(Mpa)

——

——

——

0.35

0.35

0.35

0.35

Pressure   gauge indication range(Mpa)

0~0.25

0~0.25

0~0.25

0~0.25

0~0.25

0~0.25

0~0.25
